Max liquid flow rate:

• Plastic pumps: 820 l/min (Rubber) 640 l/min (PTFE)
• Metallic pumps: 950 l/min (Rubber) 640 l/min (PTFE)

Wetted body material options: PPG, PVDF, Aluminium, Stainless Steel

Characteristics:

• 3" flange type liquid connections
• Aluminium air motor section
• Independent pilot valve actuated spool switching movement
• LOOPED C® spring assisted air spools
• Ball check valves
• Higher speed lighter weight pump design
• Able to achieve very high flow rates & high heads
• Resists stalling and freezing in most conditions
• 100% outside accessible spool
• Single external exhaust port
• Oil & grease lubrication free operation
• Zero exhaust air emissions

Typical aplications:

• General industrial proccess / Liquid transfer applications
• Pumping continuously for very long periods
• Operating with very high liquid flow rates
• Frequent start stop applications utilizing an air shut off valve
• Occasional dead heading

Max liquid flow rate:

• Plastic pumps: 1 to 760 l/min
• Metallic pumps: 1 a 800 l/min

Wetted body material options: PPG, PVDF, Aluminium, Stainless Steel

Characteristics:

• Specially designed for very tough liquid transfer applications
• 3" flange type liquid connections
• Aluminium air motor section
• Mechanically actuated spool switching movement
• Coil spring assisted air spools
• Ball check valves
• Powerful heavy weight pump desing
• Able to achieve very high flow rates & high heads
• Efficiently with inherent reliability, even in demanding situations
• Resists stalling and freezing in all conditions
• 100% outside accessible spool
• Double external exhaust port
• Oil & grease lubrication free operation
• Zero exhaust air emissions

Typical aplications:

• Pumping against very high back pressures
• Operating with very high air inlet pressures
• Frequent or extended dead heading
• Operating at very slow switching speeds
• Operating with very low air inlet pressures
• Pumping continuously for very long periods
• Frequent start stop applications utilizing either liquid or air shut off valves
• Operating with very long discharge lines
• Filter press applications
• Where pump icing / freezing is a common ocurrence
• Where air consumption efficiency is a critical factor in pump choice
